Postprocess

This section contains settings of the rendering post-processeses: refraction, motion blur, and volumetric shadows.

Post-Process Settings

Refraction Red

Refraction displacement for red channel (based on the refraction texture of refractive materials). It can be used to create light dispersion (chromatic aberrations).

By the default value of 0, there is no dispersion for refracted light in red channel.

$No refraction dispersion$

No Refraction Dispersion

$Refraction Red and Green$

Dispersion Per Channel: Red = 0.8, Green = 0.9, Blue = 1

Refraction Green

Refraction displacement for green channel (based on the refraction texture of refractive materials). It can be used to create light dispersion (chromatic aberrations).

By the default value of 0, there is no dispersion for refracted light in green channel.

Refraction Blue

Refraction displacement for blue channel (based on the refraction texture of refractive materials). It can be used to create light dispersion (chromatic aberrations).

By the default value of 0, there is no dispersion for refracted light in blue channel.

Sharpen Intensity

Specify the intensity of the image sharpness

FXAA Intensity

Specifies the intensity of FXAA smoothing

Shadow Shafts Exposure

Specify the intensity of the shadow shafts

Shadow Shafts Length

Specify the length of the shadow shafts
